浙江宁波双利吹塑机吹瓶机厂家

价格
起批量
93000.00
1
商品货号
8872063
物流
浙江 宁波市
x
北京 天津 上海 重庆 河北 辽宁 黑龙江 吉林 山东 山西 安徽 浙江 江苏 江西 广东 福建 海南 河南 湖北 湖南 四川 云南 贵州 陕西 甘肃 青海 宁夏 内蒙古 广西 西藏 新疆 香港 澳门 台湾
请选择省份
标准价 :
¥93000.00
支付方式
保障服务
订购数量 :
起订量 (台) 标准价 采购量 是否有货
≥0¥93000.00
有货
总价
93,000.00

SLBY系列;

1:此机结构精简,高速,稳定而且节能,不仅能满足快速生产需要,而且操作容易,全自动化生产。

2:模头系统:采用中心入料分流式和芯型互补流道式,型胚壁厚均匀,换色快捷,从单层到三层满足客户不同的需求。

3控制系统:整机动作控制采用PLC人机界面,显示机械动作的实时监控功能,可显示多种语言,如,中文,英文等,实现系统多功能和智能化。

4挤出系统:采用变频调速电机驱动和硬齿面减速器,螺杆设计既能满足高产量,也能保证塑化均匀。

5:开合模系统:单,双工位平移 高精度线性导轨 大梁壁圆柱轴,机器运行更稳定。

SLBY series;

1: this machine structure is compact, high-speed, stable and energy saving, not only to meet the needs of rapid production, but also easy to operate, fully automated production.

2: the die head system: using the central feeding and core type complementary flow channel type, the type of embryo wall thickness uniformity, color change fast, from single layer to the three layer to meet the different needs of customers.

3 control system: the machine action control using PLC man-machine interface, display the real-time monitoring function of the mechanical movement, can display a variety of languages, such as, Chinese, English, etc., to achieve the system and intelligent.

4 extrusion system: using VVVF motor drive and Hardened reducer, screw design can meet the high yield, but also to ensure uniform plasticizing.

5: clamping system: single, double shift high precision linear guide large cylindrical shaft wall, the machine more stable.

规格参数
型号 SLB-55   电控系统 1
螺杆长径比 1:25   适用范围 1-100
重量 3000  (kg) 外形尺寸 1600*2800*2200  (mm)
品牌 双利   样式 卧式
适用原料 PE   吹膜厚度 ≥0.07mm
螺杆直径 65mm   螺杆转速 750rpm
生产速度 60kg/h   工作电压 ≥380V
电动机功率 ≤15KW   机头膜口直径 75mm
薄膜最大折径 ≥45mm   薄膜单面厚度 ≤1600mm
执行标准 国标   产品认证 IOS9001
加工定制 是   是否进口 是
包装参数
体积(m²) 0
产品重量(kg) 3000
