温馨提示：价格参数仅供参考，详情请来电或旺旺咨询！SJ-C75、90、105、120高速吹膜机组
Series High Speed Film Blowing Machine Set
用途/USE
用于吹制高低压聚乙烯，产品广泛用于复合膜，包装膜，农业复盖膜，纺织品，服装袋或膜等包装；主电机采用变频调速，增加了主机调速的稳定性，并可节电30%，螺杆料筒采用38铬钼铝，经氮化处理，牵引机架采用升降式，不管吹大、小规格薄膜均能使其冷却效果达到最佳。
It is used for blowing high-low pressure polyethylene, which has been widely used for producing laminating film, packing film, agricultural covering film, bag or film for textile and clothing and other pacing material. The main motor adopts frequency control of motor speed to improve the speed regulating stability of main motor and save electricity by 30%. The screw and material barrel adopt 38 chrome-molybdenum aluminum which has been nitrogen treated and the traction frame adopts lifting type. No matter what size the film is, big or small, it can achieve the best effect of cooling.
选择性配置Optional Equipments：
HYDRAULIC NET CHANGER
主要技术参数/Main Technical Parameter
型号Model | SJ-C75 | SJ-C90 | SJ-C105 | SJ-C120 |
螺杆直径Screw Diameter | Φ75 | Φ90 | Φ105 | Φ120 |
螺杆长径比Screw Ratio L/D | 28：1 | 28：1 | 28：1 | 28：1 |
螺杆转速Screw Speed | 15-100r/min | 15-100r/min | 15-100r/min | 15-100r/min |
主电机功率Main Motor Power | 37kw | 45kw | 55-75kw | 75-95kw |
最大挤出量Main Output | 120kg/h | 160kg/h | 190kg/h | 220kg/h |
薄膜厚度单面Single-sided Thickness of Film | 0.01-0.08mm | 0.01-0.08 mm | 0.01-0.08 mm | 0.01-0.08 mm |
薄膜最大折径Max. Folding Width of Film | 1500mm | 2000mm | 2200mm | 2500mm |
总功率Total Power | 46kw | 60kw | 78kw | 95kw |
外形尺寸Overall Dimension | 7100*3200*6000mm | 8050*3550*8000mm | 9500*4000*9500mm | 10200*4200*12000mm |
机器重量Weight of Machine | 4T | 8T | 10T | 12T |
