型号Type | SJ-90-2200 | SJ-100-2700 | SJ-120-3200 | SJ-140-4200 | SJ-150-4700 | SJ-160-5200 |
薄膜最大折径 Max.Layflat Width mm | 2000 | 2500 | 3000 | 4000 | 4500 | 5000 |
薄膜厚度 Film Thichness mm | 0.001-0.15 | 0.001-0.15 | 0.001-0.15 | 0.01-0.25 | 0.01-0.25 | 0.01-0.25 |
最大产量Max.Output kg/h | 160 | 200 | 260 | 300 | 350 | 420 |
适应原料Raw Material | HDPE/LLDPE/LDPE/EVA |
螺杆直径 Screw Diameter mm | Φ90 | Φ100 | Φ120 | Φ140 | Φ150 | Φ160 |
螺杆长径比 Screw L/D Ratio L/D | 28:1 | 30:1 | 30:1 | 28:1 | 30:1 | 30:1 |
螺杆最大转速Screw Max.Rotation Speed | 100r/min | 100 r/min | 100 r/min | 100r/min | 100 r/min | 100 r/min |
主电机功率Extruder Driving Power kw | 45 | 75 | 90 | 110 | 130 | 160 |
主机换网形式 The Way of Screen Changing of Extruder | 液压/气动/手动双工位快速换网Hydraulic/Peneumatic/Manual Twin-station Changing Screen Quickly |
机头结构Die Structure | 螺旋式Spiral Approach |
风环结构形式 Air-ring Srtucture | 单风口（旋转双风环Cual-lip of Rotary Die） |
旋转牵引系统 | 薄膜转折方式Film Turning Mode | 水平Horizontal |
Reversing Haul-off System | 机头旋转角度Angle of Reversing the die | 3600 |
牵引及收卷速度Take-off Wind-up Speed | 0-60 r/min | 0-60 r/min | 0-60 r/min | 0-60 r/min | 0-60 r/min | 0-60 r/min |
总功率 Total Power kw | ≈75 | ≈95 | ≈120 | ≈150 | ≈180 | ≈260 |
外形尺寸 Overall Dimensions(L×W×H) M | 7.5×3.2×8 | 8.5×3.7×8 | 10×4.2×8 | 11×5.2×9 | 13×5.8×10 | 16×6.5×10 |
重量Weight | ≈9 | ≈14 | ≈16 | ≈20 | ≈24 | ≈30 |
