1.设计合理，结构简洁。
2.单片机、步进电机控制，袋长设定方便，准确。
3.调速简单、快捷。
4.自动完成制袋、充填、计数、封口、切断的全部包装过程。
5.文本显示屏操作，调整方便，自动化程度高。
6.先进的光电数控制袋系统、下膜平稳准确，制袋长度能在操作面直接设定。
7.光标对版，可获得准确的商标图案。
8.该机据不同物料可选配螺杆或量杯计量装置。
9.可选配色带打码机、充气装置(气源自备)。
(1)Reasonable design, simple structure.
(2)Controlled by single-chip computer, stepping motor, convenient
and correct bag length setting.
(3)Simple, fast speed regulation.
(4)Automatic completion for bag-making, filling, counting, sealing and cutting
(5)text display screen operating, convenient adjustment, high automation.
(6)Advance sensor digital-control bag making system, stable, correct bottom film run, bag length can be directly set up at operating side.
(7)Plate alignment by cursor, correct brand design can be achieved.
(8)Metering screw stem or glass devices can be optional in this machine according to different materials.
(9)Optional: ribbon coding machine. , gas-filled device (air source supplied by users).
适用于医药、食品、植物种子、化工产品等有一定流动性、松散无粘性粉状、颗粒状物料的自动包装，如：奶粉、面粉、冲剂、小丸、味精、白糖、汤料、麦片、干燥剂等。
Suitable for automatic packaging liquid, loose non-adhesive powder, particle materials like milk powder, flour, gourmet, sugar, soup, wheat and drying agents.
包装速度 | Packing speed | 60-100bags/min |
制袋尺寸 | Bag-making size | (L)30-200mm (W)50-150mm |
计量范围 | Filling range | 10-200ml |
包装材料 | Packing materials | OPP/CPP PET/PE 等复合材料 |
包装膜宽 | Film width | 100-300mm |
薄膜厚度 | Film thickness | 0.03-0.10mm |
耗气量 | Air consumption | 0.36m3/min 0.6MPa |
电源功率 | Power supply | AC220V 50-60Hz 1.5kw |
机器尺寸 | Machine dimensions | (L)700×(W)900×(H)1750mm |
整机重量 | Machine weight | 300kg |
