用途:
本机适用于各种低密度聚乙烯（LDPE）,高密度聚乙烯（HDPE）薄膜封切本色袋，彩印带等。广泛应用于食品包装，服装包装，工业，电器产品包装。
特点：
1、制袋自动计数，自动报警。
2、电光跟踪准确，制袋误差超过3个，机器自动停机。
3、制袋长度由按键控制。
主要技术参数：
| 型号 | TL-600 | TL-800 | TL-900 | TL-1000 | | 最大封切宽度 | 550mm | 650mm | 850mm | 950mm | | 封切长度 | 1600mm | 1600mm | 1600mm | 1600mm | | 封切厚度 | 0.006-0.10mm | 0.006-0.10mm | 0.01-0.10mm | 0.01-0.10mm | | 长度误差 | ±1mm | ±1mm | ±1mm | ±1mm | | 制袋速度 | 40-120pcs/min | 40-120pcs/min | 40-120pcs/min | 40-120pcs/min | | 主机功率 | 1.5kw | 1.5kw | 1.5kw | 1.2kw | | 加热功率 | 1.5kw | 1.5kw | 2kw | 2.5kw | | 总功率 | 3.2kw | 3.2kw | 4kw | 5.5kw | | 机器重量 | 700kg | 820kg | 900kg | 1100kg | | 外型尺寸 | 2800×1200×1350mm | 2800×1300×1350mm | 2800×1500×1350mm | 2800×1700×1350mm |
|
Use:
It is used for blowing various plastic films of low-high density polythylene natural colour bag and colour printing bag, which are widely used for packing food ,garments, industrial products and electric appliances etc.
Characteristics:
1.Automatic bag-making counting and automatic alarm.
2.with accurate photoelectric eye tracking, the machine can be automatically stopped when bag making error exceeds 2 pieces.
3.The length of the bag is controlled by the button switch.
Main technical parameter
| Model | TL-600 | TL-800 | TL-900 | TL-1000 | | Max.Cutting Width | 500mm | 700mm | 800mm | 900mm | | Making Length | 1000mm | 1000mm | 1000mm | 1000mm | | Making Speed | 0.006-0.10mm | 0.006-0.10mm | 0.01-0.10mm | 0.01-0.10mm | | Length Error | ±1mm | ±1mm | ±1mm | ±1mm | | Bag-making Speed | (40-120)x2pcs/min | (40-120)x2pcs/min | (40-120)x2pcs/min | (40-120)x2pcs/min | | Power of Main Machine | 1.5kw | 1.5kw | 1.5kw | 2.2kw | | Power Of Heating | 1.2kw | 1.5kw | 2kw | 2.5kw | | Total Power | 4kw | 4.5kw | 5.5kw | 6.5kw | | Weight of Machine | 700kg | 820kg | 900kg | 1000kg | | Overall Dimension | 2800×1200×1350mm | 2800×1300×1350mm | 2800×1500×1350mm | 2800×1700×1350mm |
|
本机免费安装调试，保修一年。公司地址:上海奉贤区青村镇林海公路6649号
联系电话;13671988769
