| | 型號Model | Unit | 350规格表 |
| 射出系統 | 螺杆直徑Screw Diameter | mm | 32 |
| 射出壓力Injection pressure | kg/cm² | 1367 |
| 理論射出容量Theorfical Shot Volume | cm³ | 96 |
| 射出量(PS)Max.shot Weight(PS) | g/0z | 87/3 |
| 射出率Injection Rate | cm²/see | 67 |
| 螺杆行程Screw stroke | mm | 125 |
| 螺杆轉速Screw Speed Max | rpm | 0-215 |
| 射嘴接觸力Nonzzle Contactforce | tf | 4.5 |
| 射嘴行程Nonzzle Retraction Stroke | mm | 190 |
| 溫度控制段數Number of temperature Contorl | | 3 |
| 鎖模系統 | 鎖模力Clampieng Force | tf | 40 |
| 模板尺寸Plateu Size | mm | 600*340 |
| 模柱間距Disitance Betqeen Tie Bare | mm | 450*240 |
| 最小模厚Min.Mold Height | mm | 145/80 |
| 開模行程Oprening Stroke | mm | 200 |
| 最大開模距Max.Mold Height | mm | 360/295 |
| 頂出力量Ejector Stroke | tf | 1.7 |
| 頂出行程Ejector Strke | mn | 35 |
| 油壓電力系統 | 最大液壓壓力Max.Hydaulic Pressure | kg/cm² | 140 |
| 泵浦葉出量Pump Output | l/min | 41 |
| 作動油量Oil Resservoir Capacity | l | 120 |
| 冷却水用量Cooling Water Cousumption | l | 600-800 |
| 馬達電力Pump Motor Power | kw | 5.5(7.5HP) |
| 電熱容量Borrl Heating Power | kw | 2.4 |
| 總用電量Total Weight | kw | 8.4 |
| 其它 | 機器總重Machine Weight | kg | 1800 |
| 機器外型尺寸Machine Dimensious(LsWsH) | m | 1.4*0.9*2.75 |
| 裝箱重量Shipping Weight | kg | 2100 |
| 裝箱尺寸Shipping Dimensious(LsWsH) | m | 1.6*1.1*2.3 |
