产品用途：
该机组主要用于大口径PE保温管的生产，产品主要应用于供暖管道的外层，中间层为聚氨酯发泡层，内层为钢管；也可生产供水管、排水管等。
生产线组成部分：
该条生产线主要由挤出机、模具、真空定径、牵引机、小跑车、电气控制系统等组成。
Product uses:
This production line is designed for producing large-diameter black & yellow PE insulating pipes which are applied to the outer layer of heating pipeline ,water supply pipeline and drainge pipeline.
Main devices of the production line:
This production line consists of extruder,haul-off machine,vaccum calibration,PE pipe supporting devive and electrica control system..
主要参数：
Parameter
规格型号 Specification | 拉管范围(mm) Pipe diameter | 总功率（KW） Total power | 产量（Kg/h） Output | 长径比（L/D） L/D ratio | 中心高(mm) Centre-height |
BL-65 | 90-180 | 70 | 30-120 | 30:1 | 1000 |
BL-90 | 200-420 | 110 | 50-220 | 30:1 | 1000 |
BL-120 | 265-655 | 258 | 100-350 | 30:1 | 1100 |
BL-150 | 760-1155 | 310 | 200-500 | 30:1 | 1200 |
BL-180 | 960-1420 | 380 | 250-750 | 30:1 | 1200 |
BL-200 | 1275-1800 | 450 | 300-800 | 30:1 | 1200 |
规格及标准设备若有变动，恕不另行通知。
Specifications and standard equipment are subject to change without notification
