Model
BHW190
Engine发动机
ETERNUS 13.5匹
Type
4-Stroke OHV 1 cylinder
Displacement
389 c m³
Bore x Stroke
88 x 64 mm
Generator发电机
Rated voltage额定电压
220V(AC)
Rated frequency
50Hz / 60Hz
Rated current额定电流
9.1A(AC)
Rated output 50Hz额定输出功率
5.0kVA(AC)
Rated output 60Hz额定输出功率
Welding Rated output
2.0kW(AC)
Rated power factor功率因数
CosΦ = 1.0
Phase
Single
2-pole,rotating type
DC Welder直流电焊机
Rated Max.current (A)额定最大电流
180
Load voltage(V)约定电压
27.2
Current range(A)电流范围
50-180
Max.current duty cycle(%)负载持续率
20
Applicable welding rod diameter适用焊条直径
2.5mm-5.0mm
Rated revolution额定转数
3600r/min
No-load voltage(A)
70
Idle control节流阀
Automatic自动
Rectifier type
Six phase half wave rectifier
Fuel tank capacity燃油箱容量
17L
Length x width x height(mm)尽寸
690x510x 520
Net weight(kg)净重
86
