机型简介Means of indicators
为迎合市场需要，耐力激光研发和推出了激光大面积大功率切割裁床。满足了客户大面料,大图样,量高生产需求。
To meet the needs of the market, sharplaser developed and
promote cutting bed models to meet the requirement of large size material, big
size patters and high quantities production.
机器优点
大面料,大图样首选设备
大大节约上料时间,提高工作效率
切割精准，无焦边、无黄边。
系统轻巧，节省空间，操作简易。
完善光学系统，激光功率稳定，寿命长。
美国进口电机及驱动系统配置高精密同步系统，实现快速切割和高精度。
三种数据交互（U盘、PC、网络）
软件支持AI、PLT、BMP、JPG、DXF、DST多种格式，无缝兼容CorelDRAW、CAD、PHOTOSHOP，等图文软件，方便操作
采用LAN接口，双向通讯，提高传送速度和准确性；可实现一台电脑控制多达254台
Machine Advantage
The first option of large size
material and big cutting patterns
To save greatly material loading
time and improve work efficiency
Hight cutting precision,
no burn, no yellow mark
Easy/friendly operation system
Perfect optical system
U.S.A step motor &
driving system with high precision synchronization system to make sure fast
cutting speed and high precision.
Interactive three kinds
of data( U disk ,PC ,internet)
software support multiple
formats: AI, PLT, BMP, JPG, DXF, DST, seamless compatibility CorelDRAW,
CAD, PHOTOSHOP, and other graphic
software, easy operation
A LAN interface, two-way
communication, to improve transmission speed and accuracy; allows a computer to
control up to 254 laser equipment, greatly reduces the user cost of investment.
适用材料
本类机型机器适用于布料、皮料、PU、木料、电子电器、纸张、压克力等行业
Applicable Materials
This kinds of model apply
widely to fabric, leather, PU, wood, MDF, electronic parts, paper, acylic.......ect.
适用行业
本类机型机器适用于服装绣花、皮革制品、竹木制品、电子电器、模型、工艺品、广告、包装印刷、纸制品等行业
Applicable Industry
This kinds of model apply
to cloth,leather, tabuectoy,electronics and electronic appliance,model,crafts
gift, the advertising,package printing,paper products industry.
技术参数Technical Parameter：
机 型machine model | cutting bed |
激光器类型laser tube | 国产封离式CO2激光器 China-made CO2
glass laser tube |
冷却方式cooling way | 水冷water cooling |
激光功率laser power | 80W/100W/130W/150W(选配/optional) |
切割速度cutting speed | 0-800mm/s |
雕刻速度engraving speed | 0-1500mm/s |
重复定位精度repeating precision | ±0.05mm |
加工范围Working area | 3000x1600mm |
电 源power supply | 1PH+1 AC 220V
15A 50/60HZ |
外型尺寸machine measure (长Lx宽Wx高H) | 3500*2100*750mm |
包装尺寸packing size (长Lx宽Wx高H) | 3550*2150*900mm |
重 量Weight | 约/Around：净重/N.W 1100kg，毛重/G.W 1200kg |
环境要求environment requirement | 温度Temperature 15℃-35℃,湿度humidity 30%-80%（无结露noncondensing） |
