1BJX系列悬挂轻耙主要适用于农田的耕后碎土、播前整地、疏松土壤、土肥混合和轻质土壤的灭茬作业。该机具有结构合理、坚固耐用、使用方便、保养易行，入土碎土能力强，耙后地表平整的特点。
The machine is suitable for pulverizing and loosening clods after plowing and for planning the land before sowing on cultivated land, it can make soil and fertilizer mix up, and clean away the stump of plants. With the reasonable structure, the machine is durable in service, easy to be operated and maintained, the land surface is smooth.
Model 1BJ-4.4 with 40 discs folded wing middle-duty disc harrow is suitable for operation on middle and light soil as harrowing instead of plowing, loosening soil before sowing, cleaning residues of crops and weeds. The machine has the merits of high efficiency and reasonable utilization of the power, well ability of crushing soil, working width is wide and transportation width is narrower, etc. It is easy to be mounted and adjusted, reverse freely, and convenient for transportation.
主要参数：Main Specifications
型号Model | 1BJX-1.8 | 1BJX-2.0 | 1BJX-2.2 | 1BJX-2.4 | 1BJX-2.5 | 1BJ-4.4 |
外型尺寸(cm) L*W*H
Overall dimension | 1850*201*132 | 198*224*132 | 198*247*132 | 278*247*132 | 297*268*146 | 542*432*113 |
耕幅(m)
Working width | 1.8 | 2.0 | 2.2 | 2.4 | 2.5 | 4.4 |
耕深(mm)
Working depth | 140 | 140 | 140 | 140 | 140 | 140 |
耙片数量(片)
Nos of disc | 16 | 18 | 20 | 22 | 24 | 40 |
耙片直径(mm)
Dia. of disc | 560(610) | 560(610) | 560(610) | 560(610) | 560(610) | 560(610) |
整机重量(kg)
Weight | 390 | 434 | 463 | 604 | 760 | 1750 |
配套动力(kw)
Fitted power | 33 | 37~44 | 37~47.8 | 47.8 | 54.9 | 55-73.5 |
挂接形式
Linkage | 三点悬挂(Standard three-point mounted) | 牵引(Trailed) |
售后及维修服务 ：
本店承诺：所有的机械都是厂家直销销售，所有产品都是100%全新，量大可以优惠。放心选购。
按国家规定质保一年，在此期间如有质量问题我司免费提供维修件，如属人为损坏质量问题可有偿提供维修部件（易损件不在质保范围之内）。
我们竭诚欢迎您的来访洽谈！
欢迎联系我们
联系人：黄经理
电话：15552630010
网址：www.yilimachine.com
厂址：山东省禹城市万庄工业园
