Items 项目内容 | Units 单位 | Parameters 参数 |
JB40 |
Whole performance of machine | 整机性能 | Max.theo. concrete output 最大理论混凝土输送量 | m3/h | 40 |
Max.concrete pumping pressure 最大泵送混凝土压力 | MPa | 10 |
Distribution valve type 分配阀形式 | | S管阀 S Valve |
Concrete cylinder diameter×stroke 混凝土输送缸缸径×行程 | mm | Ф160×1000 |
Hopper capacity 料斗容积 | L | 400 |
Outlet diameter 出料口直径 | mm | Ф125 |
Power system | 动力系统 | Diesel engine model 柴油机型号 | | 潍柴道依茨 |
Electrical engineering power 额定功率 | kW | 82 |
Rotate speed 额定转速 | r/min | 2300 |
Hydraulic system | 液压系统 | Circuit type 液压油路形式 | | Open circuit 开式回路 |
Pumping system pressure 泵送系统油压 | MPa | 32 |
Distribution system pressure 分配系统油压 | MPa | 14 |
Mixing system pressure 搅拌系统油压 | MPa | 6 |
Capacity of oil tank 液压油箱容积 | L | 350 |
| The biggest transportation is away from vertically (/Level) 最大输送距离 垂直/水平 | m | 150/600 |
Other parameters | 其它参数 | Max.aggregate diameter 允许最大骨料粒径 | mm | Scree碎石: 30 |
Inside diameter of delivering pipe 混凝土输送管内径 | mm | Ф125 |
Dimensions：length×width×height 外形尺寸：长×宽×高 | mm | 6000x2300x2600 |
Total weight总质量 | kg | 4500 |
