重量：91KG
功率：5-5.5HP
离心力：16KN
爬坡能力：20°
发动机转速：3600R.P.M
行驶速度：20-25KM/MIN
底板尺寸：60*50cm
包装尺寸：65*56*72cm
Product Description
1) Plate compactor is Easy-to-reach control
2) Plate compactor with Large shock mounts reduce vibration of handle.
3) Plate compactor with heavy-duty shock mounts vibration of upper deck.
4) Plate compactor with wear-resistant base plates open design reduces dirt building.
5) Plate compactor with centrally-located lifting bar transport in and out of trenches.
6) Plate compactor with wrap around protection frame protects the compactor from accidental job-site damage.
7) Plate compactor is equipped With extension plate
Application:
Mechanical control system reflects a reliabilityk economy with machine and low maintenance design, compaction depths up to 900mm. Sewer trenches, general road-building projects, compacting foundations and backfills are all standard jobs for our heavy-duty plate compators.
Features and Benefits:
Reversible handle control for forward and backward compaction;
Wear-resistant base plates extend life, open design reduces dirt building;
Centrally-located lifting bar allows easy transportation in and out of trenches;
Semi-covered protection cage protects the plate from accidental job-site damage;
Large shock mounts reduce vibration to the upper engine and handle;
Rubber&canvas mat for brick paving compaction as option.
