DKLGZ系列全自动刮渣式油炸流水线
DKLGZ series automatic blow slag type Fried assembly line
本机主体使用SUS304不锈钢制作。
采用纯油过滤的工艺,容油量少,可提高炸油的更换率。
双层网带(编织网带SUS304材质)输送产品,速度可调。
微电脑控制,设有油温过高报警系统。
底部刮渣采用变频调速,刮渣速度可根据残渣的多少控制,残渣通过刮渣器直接刮到沥油车内,能及时将残渣沥油清除。
This machine is main use SUS304 stainless steel.
It adopts pure oil filter technology, let oil quantity is little, it can improve the GengHuanLv frying oil.
Double-deck net belt (woven mesh belt SUS304 material), speed adjustable conveying products.
Microcomputer control, with the oil temperature exorbitant alarm system.
Scrape the bottom slag frequency-inverter regulation, scraping the slag speed can be according to how much control, scraps of residue by scraping the dregs device directly to drain youchegang scraping within, can prompt will residue drain oil removal.
主要技术参数
The main technique parameters:
型号 Model | 网带宽度 Mesh belt width | 温度范围 Temperature range | 生产能力 Production capacity | 容油量 Let oil | 外部尺寸(mm) Shape dimension | 能源 Energy |
DKLGZ-5000 | 600mm | 0-300℃ | 300-500kg/h | 1000L | 5000×1200×2200 | 电、煤炭 Electricity coal 然气 gas 柴油 diesel 导热油炉 Heat conduction oil furnace |
DKLGZ-6000 | 600mm | 0-300℃ | 600-800kg/h | 1500L | 6000×1200×2200 |
DKLGZ-8000 | 800mm | 0-300℃ | 1000kg/h | 2500L | 8000×1500×2200 |
注:特殊尺寸及要求可根据用户需求制作
